5 STANDARD SERIES FRL -

PRESSURE SWITCH

CODE BODY DESCRIPTION €
SIZE
5612S202 P44
5613S203 1 G1/4” M8 Connector
5623S203 1 G3/8” M8 Connector 54.41
5624S204 2 G3/8” M8 Connector 54.41
5625S205 2 G1/2” M8 Connector 78.73
5626S206 2 G3/4” M8 Connector 78.73
2 G1” M8 Connector 85.87
85.87

TECHNICAL DATA SIZE 1 SIZE 2

Maximum pressure bar 15 13

Maximum currant A 2 2

Maximum voltage V 250 250

Outside diameter of cable mm 4.9 4.9

Fluid Filte red lubricated or unlubricated compressed air. Lubrication, if used, must be continuous

Mounting position In any position In any position

Wall fixing screws No. 2 M4 screws No. 2 M5 screws

FILTER REGULATOR + LUBRICATOR SET

CODE BODY DESCRIPTION €
SIZE
5612B24L102 P44
5612B54L102 1 20 Micron 0-8 Bar G1/4” Manual Drain
5613B24L103 1 20 Micron 0-8 Bar G1/4” Auto Drain 60.78
5613B54L103 1 20 Micron 0-8 Bar G3/8” Manual Drain 78.65
5623B24L103 1 20 Micron 0-8 Bar G3/8” Auto Drain 60.78
5623B54L103 2 20 Micron 0-8 Bar G3/8” Manual Drain 78.65
5624B24L104 2 20 Micron 0-8 Bar G3/8” Auto Drain 105.17
5624B54L104 2 20 Micron 0-8 Bar G1/2” Manual Drain 124.21
5625B24L105 2 20 Micron 0-8 Bar G1/2” Auto Drain 105.17
5625B54L105 2 20 Micron 0-8 Bar G3/4” Manual Drain 138.50
5626B24L106 2 20 Micron 0-8 Bar G3/4” Auto Drain 119.46
5626B54L106 2 20 Micron 0-8 Bar G1” Manual Drain 138.51
2 20 Micron 0-8 Bar G1” Auto Drain 119.46
138.51

TECHNICAL DATA SIZE 1 SIZE 2

Input pressure bar 15 13

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 350 1200

∆P 0.5 bar (0.05 MPa; 7 psi)

Weight g 414 409 400 1074 1047 1043 1031

Mounting position Vertical Vertical

Wall fixing screws No. 2 M4 screws No. 2 M5 screws
