Page 266 - floMAX Catalogue 2016

5 STANDARD SERIES FRL -

STANDARD FILTER REGULATOR

CODE BODY DESCRIPTION €
SIZE
5612B242 P44
5612B542 1 20 Micron 0-8 Bar G1/4” Manual Drain
5612B262 1 20 Micron 0-8 Bar G1/4” Auto Drain 34.56
5612B562 1 20 Micron 0-12 Bar G1/4” Manual Drain 52.41
5613B243 1 20 Micron 0-12 Bar G1/4” Auto Drain 34.56
5613B543 1 20 Micron 0-8 Bar G3/8” Manual Drain 52.41
5613B263 1 20 Micron 0-8 Bar G3/8” Auto Drain 34.56
5613B563 1 20 Micron 0-12 Bar G3/8” Manual Drain 52.41
5623B243 1 20 Micron 012 Bar G3/8” Auto Drain 34.55
5623B543 2 20 Micron 0-8 Bar G3/8” Manual Drain 52.41
5623B263 2 20 Micron 0-8 Bar G3/8” Auto Drain 58.42
5623B563 2 20 Micron 0-12 Bar G3/8” Manual Drain 77.47
5624B244 2 20 Micron 0-12 Bar G3/8” Auto Drain 58.42
5624B544 2 20 Micron 0-8 Bar G1/2” Manual Drain 77.47
5624B264 2 20 Micron 0-8 Bar G1/2” Auto Drain 58.43
5624B564 2 20 Micron 0-12 Bar G1/2” Manual Drain 77.47
5625B245 2 20 Micron 0-12 Bar G1/2” Auto Drain 58.43
5625B545 2 20 Micron 0-8 Bar G3/4” Manual Drain 77.47
5625B265 2 20 Micron 0-8 Bar G3/4” Auto Drain 65.58
5625B565 2 20 Micron 0-12 Bar G3/4” Manual Drain 84.63
5625B246 2 20 Micron 0-12 Bar G3/4” Auto Drain 65.58
5625B546 2 20 Micron 0-8 Bar G1” Manual Drain 84.63
5626B266 2 20 Micron 0-8 Bar G1” Auto Drain 65.58
5626B566 2 20 Micron 0-12 Bar G1” Manual Drain 84.63
2 20 Micron 0-12 Bar G1” Auto Drain 65.58
84.63

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure bar 15 13

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 500 800 2200 3200 4300 5200

∆P 0.5 bar (0.5 MPa; 7 psi)

Weight g 244 239 230 623 596 592 580

Bowl capacity cm3 30 70

Mounting position Vertical Vertical

Wall fixing screws No. 2 M4 screws No. 2 M5 screws

STANDARD LUBRICATOR

CODE BODY DESCRIPTION €

SIZE P44

5612L102 1 G1/4” 26.21
26.21
5613L103 1 G3/8” 46.74
46.74
5623L103 2 G3/8” 53.89
53.89
5624L104 2 G1/2”

5625L105 2 G3/4”

5626L106 2 G1”

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure bar 15 13

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 1300 1700 2200 2300 3900 3900

∆P 0.5 bar (0.5 MPa; 7 psi)

Weight g 185 180 171 480 453 449 437

Quantity of filled oil cm3 60 130

Mounting position Vertical Vertical

Wall fixing screws No. 2 M4 screws No. 2 M5 screws
