STANDARD SERIES FRL - 5

SHUT-OFF VALVE

CODE BODY DESCRIPTION €
SIZE
5612V102 P44
5612V202 1 G1/4” Manual
5612V702 1 G1/4” Pneumatic 32.76
5613V103 1 G1/4” Solenoid* 32.76
5613V203 1 G3/8” Manual 46.52
5613V703 1 G3/8” Pneumatic 46.52
5623V103 1 G3/8” Solenoid* 65.57
5623V203 2 G3/8” Manual 65.56
5623V703 2 G3/8” Pneumatic 49.49
5624V104 2 G3/8” Solenoid* 80.26
5624V204 2 G1/2” Manual 84.47
5624V704 2 G1/2” Pneumatic 49.49
5625V105 2 G1/2” Solenoid* 80.26
5625V205 2 G3/4” Manual 84.47
5624V705 2 G3/4” Pneumatic 56.62
5626V106 2 G3/4” Solenoid* 87.39
5626V206 2 G1” Manual 91.61
5624V706 2 G1” Pneumatic 56.62
2 G1” Solenoid* 87.39
91.61

*SOLENOID COIL NOT SUPPLIED. SEE PAGE 392.

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure for pneumatic & solenoid bar 15 13

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 800 1000 1100 2800 3000 3000

∆P 0.5 bar (0.05 MPa; 7 psi)

Weight g 197 192 183 476 449 445 433

Mounting position In any position In any position

Wall fixing screws No. 2 M4 screws No. 2 M5 screws

PROGRESSIVE STARTER

CODE BODY DESCRIPTION €

SIZE P44

5612A702 1 G1/4” 85.37
85.37
5613A703 1 G3/8” 111.55
111.55
5623A703 2 G3/8” 118.68
118.68
5624A704 2 G1/2”

5625A705 2 G3/4”

5626A706 2 G1”

*SOLENOID COIL NOT SUPPLIED. SEE PAGE

TECHNICAL DATA SIZE 1 SIZE 2

Input pressure bar 3 - 10 3 - 10

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 900 1000 1100 2800 3600 3600

∆P 0.5 bar (0.05 MPa; 7 psi)

Weight g 203 198 189 503 476 472 460

Mounting position In any position In any position

Wall fixing screws No. 2 M4 screws No. 2 M5 screws
