STANDARD SERIES FRL - 5

OIL REMOVER FILTER

CODE BODY DESCRIPTION €
SIZE
5612D102 P44
5613D503 1 0.01 Micron G1/4” Manual Drain
5623D103 1 0.01 Micron G3/8” Manual Drain 60.35
5624D104 2 0.01 Micron G3/8” Manual Drain 60.35
5625D105 2 0.01 Micron G1/2” Manual Drain 99.49
5626D106 2 0.01 Micron G3/4” Manual Drain 99.49
2 0.01 Micron G1” Manual Drain 106.64
106.64

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure bar 15 13

Suggested flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 460 620

Weight g 194 189 180 483 456 452 440

Bowl capacity cm3 15 40

Mounting position Vertical Vertical

Wall fixing screws No. 2 M4 screws No. 2 M5 screws

ACTIVE CARBON FILTER

CODE BODY DESCRIPTION €
SIZE
5612C102 P44
5613C103 1 0.003 mg/m3 G1/4” Manual Drain
5623C103 1 0.003 mg/m3 G3/8” Manual Drain 60.93
5624C104 2 0.003 mg/m3 G3/8” Manual Drain 60.93
5625C105 2 0.003 mg/m3 G1/2” Manual Drain 99.49
5626C106 2 0.003 mg/m3 G3/4” Manual Drain 99.49
2 0.003 mg/m3 G1” Manual Drain 106.64
106.64

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure bar 15 13

Suggested flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 350 800

Weight g 195 190 181 483 456 452 440

Inlet Fluid 0.01 πm filtred and depurated air

Mounting position In any position In any position

Wall fixing screws No. 2 M4 screws No. 2 M5 screws

PRESSURE REGULATOR

CODE BODY DESCRIPTION €
SIZE
5612R142 P44
5612R162 1 0-8 Bar G1/4”
5613R143 1 0-12 Bar G1/4” 25.39
5613R163 1 0-8 Bar G3/8” 25.39
5623R143 1 0-12 Bar G3/8” 25.39
5623R163 2 0-8 Bar G3/8” 25.39
5624R144 2 0-12 Bar G3/8” 43.20
5624R164 2 0-8 Bar G1/2” 43.20
5625R145 2 0-12 Bar G1/2” 43.20
5625R165 2 0-8 Bar G3/4” 43.20
5626R146 2 012 Bar G3/4” 50.34
5626R166 2 0-8 Bar G1” 50.34
2 0-12 Bar G1” 50.34
50.34

TECHNICAL DATA SIZE 1 SIZE 2

Max. input pressure bar 15 13

Flow rate at 6.3 bar (0.63 MPa; 91 psi) NI/min 570 1600 2900 3000 4300 4700

∆P 0.5 bar (0.5 MPa; 14 psi)

Weight g 193 188 179 546 519 515 503

Mounting position In any position In any position

Wall fixing screws No. 2 M4 screws No. 2 M5 screws
